Buy NXP SmartMX3 Java Cards Contact/Contactless/Dual Interface Java Card

Buy NXP SmartMX3 Java Cards – Buy NXP SmartMX3 Java Cards Contact/Contactless/Dual Interface Java Card

Buy NXP SmartMX3 Java Cards are secure-microcontroller platform, while JCOP is the Java Card operating-system/product layer. NXP specifically states that JCOP 4 can run on SmartMX3 P71D321 and supports contact, contactless and dual-interface card configurations.

NXP SmartMX3 Java Cards For P71D321, NXP identifies it as a Contact and Dual-Interface Controller and lists applications including eGovernment, access management and transport. The platform supports flash configurations up to 344 KB, with up to 500 KB NVM available depending on implementation.

NXP SmartMX3 Java Cards For P71D600, NXP currently positions it as a high-memory SmartMX3 security microcontroller with up to 450 KB memory, making it particularly relevant to high-capacity JCOP Java Card products such as the J3R452 family.

One correction for technical accuracy: P71D321 and P71D600 are NXP secure microcontroller platforms, not themselves Java Cards. A finished Java Card combines the SmartMX3 chip/platform with a Java Card operating system such as JCOP. NXP explicitly describes JCOP 4 as its Java Card OS for SmartMX3 secure microcontrollers.

NXP SmartMX3 Java Cards is the secure-microcontroller platform, while JCOP is the Java Card operating-system/product layer. NXP specifically states that JCOP 4 can run on SmartMX3 P71D321 and supports contact, contactless and dual-interface card configurations.

For P71D321, NXP identifies it as a Contact and Dual-Interface Controller and lists applications including eGovernment, access management and transport. The platform supports flash configurations up to 344 KB, with up to 500 KB NVM available depending on implementation.

For P71D600, NXP currently positions it as a high-memory SmartMX3 security microcontroller with up to 450 KB memory, making it particularly relevant to high-capacity JCOP Java Card products such as the J3R452 family.

NXP SmartMX3 Java Cards – P71D321 & P71D600

NXP SmartMX3 Java Cards combine NXP’s secure SmartMX3 microcontroller technology with Java Card and GlobalPlatform technology to provide a flexible platform for secure identity, authentication, payment, access control, PKI, eGovernment and other multi-application smart card solutions.

The NXP SmartMX3 P71D321 and P71D600 platforms are designed for high-security smart card applications requiring strong cryptographic protection, secure memory, high-performance processing and reliable contact or contactless communication. NXP offers JCOP as a Java Card operating system for SmartMX3 secure microcontrollers, providing a proven platform for developing and deploying secure Java Card applications.

Buy NXP SmartMX3 Java Cards Products

The NXP SmartMX3 Java Cards family can be used as the secure hardware platform for several types of Java Cards, including:

• NXP SmartMX3 P71D321 Java Card
• NXP SmartMX3 P71D321 Contact Java Card
• NXP SmartMX3 P71D321 Contactless Java Card
• NXP SmartMX3 P71D321 Dual Interface Java Card
• NXP SmartMX3 P71D600 Java Card
• NXP SmartMX3 P71D600 High-Memory Java Card
• JCOP 4 SmartMX3 Java Cards
• JCOP 4.5 P71D600 Java Cards
• High-memory Java Card solutions based on the SmartMX3 platform

The exact interface, memory configuration, operating system, applets and personalization options depend on the specific finished card product.

What Is an NXP SmartMX3 Java Card?

An NXP SmartMX3 Java Cards is a secure smart card solution built around an NXP SmartMX3 secure microcontroller and a Java Card operating system. The SmartMX3 hardware provides secure processing, memory management, cryptographic acceleration and hardware security features, while JCOP provides the Java Card and GlobalPlatform environment required to install and manage applications.

NXP describes the SmartMX3 P71D321 as a secure and flexible microcontroller and offers a full system solution using the JCOP 4 operating system.

This architecture makes SmartMX3 Java Cards suitable for multi-application environments where several secure services need to operate on the same card while maintaining controlled application isolation and lifecycle management.

NXP SmartMX3 P71D321 Java Card

The NXP SmartMX3 P71D321 is a secure microcontroller platform designed for high-security smart card and secure identification applications.

NXP lists the P71D321 with advanced IntegralSecurity 3.0 architecture, high-performance cryptographic capabilities, fast communication and support for JCOP 4. The platform is available in memory configurations with flash capacity up to 344 KB, while NXP states that up to 500 KB of non-volatile memory can be available depending on the implementation.

P71D321 Key Features

• NXP SmartMX3 secure microcontroller platform
• SmartMX3 IntegralSecurity 3.0 architecture
• JCOP 4 operating system option
• Java Card platform support
• GlobalPlatform support through JCOP
• Flash configurations up to 344 KB
• Up to 500 KB NVM available depending on implementation
• Hardware-assisted cryptography
• High-performance secure processing
• Contact and dual-interface configurations
• Designed for secure identification and authentication
• Suitable for multi-application smart card solutions
• Common Criteria and EMVCo-oriented secure applications

NXP identifies the P71D321 as a Contact and Dual-Interface Controller and lists it for applications including electronic identification, access management and transport.

NXP SmartMX3 P71D321 Contact Java Card

An NXP SmartMX3 P71D321 Contact Java Card is a Java Card implementation using the P71D321 secure microcontroller with a contact interface based on the ISO/IEC 7816 smart card architecture.

Contact Java Cards communicate through the card’s electrical contacts and are widely used for applications requiring secure authentication, digital signatures, PKI credentials, enterprise identity and other card-based security functions.

A JCOP-based implementation provides a Java Card runtime and GlobalPlatform environment for secure application deployment and card lifecycle management.

Contact Java Card Applications

P71D321-based contact Java Cards can be considered for:

• PKI authentication
• Digital signatures
• Enterprise authentication
• Government identity
• eGovernment credentials
• Secure login
• Certificate storage
• Access control
• Secure application development
• Multi-application smart cards

NXP SmartMX3 P71D321 Contactless Java Card

An NXP SmartMX3 P71D321 Contactless Java Card uses the SmartMX3 secure platform in a contactless smart card implementation.

NXP’s JCOP documentation describes support for contactless communication using ISO 14443 and identifies JCOP as supporting contact, contactless and dual communication interfaces.

Contactless Java Cards are useful where users need to authenticate or exchange secure information simply by tapping a card against a compatible reader.

Typical applications include:

• Contactless identification
• NFC authentication
• Secure access control
• Transit and transportation
• Government identification
• Electronic passports
• Secure credentials
• Contactless payment applications
• Enterprise authentication

The final card interface and supported protocols should always be confirmed against the exact JCOP and NXP SmartMX3 Java Cards configuration being supplied.

NXP SmartMX3 P71D321 Dual Interface Java Card

The NXP SmartMX3 P71D321 Dual Interface Java Card combines contact and contactless communication in one smart card.

This configuration can provide an ISO/IEC 7816 contact interface together with ISO/IEC 14443 contactless communication, allowing the same secure card to work with different readers and infrastructures.

NXP’s JCOP 4 platform specifically supports dual-interface configurations and ISO 7816 contact communication together with ISO 14443 contactless communication.

Benefits of a P71D321 Dual Interface Java Card

• Contact and contactless operation
• Flexible reader compatibility
• Java Card multi-application architecture
• GlobalPlatform application management
• Hardware-assisted cryptography
• Secure key and credential storage
• Suitable for migration between legacy contact and newer contactless infrastructure
• Useful for identity, payment, transport and access applications

NXP also lists SmartMX3 P71D321 in its access-management solutions and electronic identification solutions.

NXP SmartMX3 P71D600 Java Card

The NXP SmartMX3 P71D600 is a newer high-memory member of the SmartMX3 security microcontroller family.

NXP SmartMX3 Java Cards currently lists the P71D600 with high memory up to 450 KB, positioning it for applications that require more memory than conventional secure microcontroller configurations.

This makes the P71D600 particularly relevant for high-memory Java Card products where multiple applets, security services, credentials and personalization data need to coexist.

NXP SmartMX3 P71D600 High-Memory Java Card

The NXP SmartMX3 P71D600 High-Memory Java Card is designed for demanding multi-application deployments that require a larger memory footprint.

A current P71D600-based JCOP 4.5 product example is the J3R452, which uses the P71D600 platform and provides approximately 450 KB of flash in a dual-interface Java Card implementation. The product information identifies support for Java Card 3.0.5 Classic, GlobalPlatform 2.3, ISO 7816 contact communication and ISO 14443 contactless communication.

High-Memory Java Card Advantages

A higher-memory NXP SmartMX3 Java Cards can provide additional capacity for:

• Multiple Java Card applets
• PKI applications
• Digital certificates
• Authentication credentials
• Secure identity applications
• Payment applications
• Access-control applications
• NFC applications
• Digital signature functions
• Personalization data
• Multi-application deployments

For projects requiring a large application footprint, the P71D600 platform provides a strong foundation for high-memory JCOP Java Card products.

SmartMX3 P71D321 vs P71D600

Feature	SmartMX3 P71D321	SmartMX3 P71D600
Product family	SmartMX3	SmartMX3
Role	Secure microcontroller	High-memory secure microcontroller
JCOP support	JCOP 4	JCOP-based high-memory solutions
Java Card applications	Yes, with appropriate JCOP implementation	Yes, with appropriate JCOP implementation
Contact configuration	Available	Product-dependent
Contactless configuration	Product-dependent	Product-dependent
Dual interface	Supported	Available in products such as J3R452
Memory	Up to 344 KB flash configurations; up to 500 KB NVM depending on implementation	Up to 450 KB memory listed by NXP
Security architecture	IntegralSecurity 3.0	SmartMX3 security architecture
Main positioning	Secure identity, access, transport and multi-application cards	High-memory secure identity and multi-application applications

The memory figures should not be interpreted as the usable Java Card application memory of every finished card. Actual available NVM, flash allocation, RAM and applet capacity depend on the specific SmartMX3 chip configuration, JCOP version and card implementation.

JCOP Java Card Operating System for SmartMX3

JCOP is an important part of the SmartMX3 Java Card ecosystem.

NXP SmartMX3 Java Cards describes JCOP 4 as a secure, field-proven Java Card operating system for secure identity chip-card applications. JCOP 4 supports Java Card 3.0.5 Classic and GlobalPlatform, as well as contact, contactless and dual-interface configurations.

JCOP also provides support for major cryptographic algorithms, including DES, 3DES, AES, RSA, ECC and SHA through hardware-based cryptographic coprocessors.

This combination of NXP SmartMX3 Java Cards and JCOP software provides a platform for developing and deploying secure multi-application cards.

Security Features of SmartMX3 Java Cards

Security is one of the primary reasons to select the NXP SmartMX3 Java Cards platform.

The P71D321 incorporates NXP’s IntegralSecurity 3.0 architecture. NXP describes security mechanisms including protection against template attacks, blinded data paths, configurable memory encryption, vertical firewall mechanisms and a Physical Unclonable Function (PUF).

NXP also lists Common Criteria EAL 6+ and EMVCo-related security certification for the P71D321 platform.

These capabilities make NXP SmartMX3 Java Cards suitable for security-sensitive applications where secure storage, cryptographic processing, application isolation and resistance to physical attacks are important requirements.

Applications of NXP SmartMX3 Java Cards

NXP SmartMX3 Java Cards and JCOP-based Java Cards can be used across a wide range of secure applications.

Government ID and eGovernment

NXP SmartMX3 Java Cards technology is used in electronic identification applications including eIDs, electronic passports, electronic health cards and electronic driver’s licences.

PKI and Digital Signatures

Java Card technology can securely store private keys and certificates and execute cryptographic operations for PKI authentication and digital signatures.

Access Control

NXP SmartMX3 Java Cards is also listed by NXP for access-management applications.

Payment

SmartMX3 platforms are designed for high-security payment and EMV-related applications. NXP cites payment as one of the established application areas for the SmartMX family.

Transportation

SmartMX3 is also positioned for transportation and secure ticketing applications, where contactless communication and secure credential management are important.

Enterprise Authentication

SmartMX3 Java Cards can provide a hardware-backed environment for enterprise credentials, authentication certificates, secure login and multi-factor authentication.

Why Choose NXP SmartMX3 Java Cards?

NXP SmartMX3 Java Cards offer a combination of secure hardware, Java Card technology, GlobalPlatform application management and flexible card interfaces.

The P71D321 is particularly suited to established contact and dual-interface smart card applications, while the P71D600 provides a high-memory platform for more demanding Java Card deployments.

For organizations developing multi-application smart cards, secure identity systems, PKI cards, access credentials or contactless security solutions, SmartMX3 provides a strong hardware foundation for Java Card applications.

Buy NXP SmartMX3 Java Cards

Looking to buy NXP SmartMX3 Java Cards for a secure identity, PKI, authentication, payment, access-control or contactless project?

Available configurations can include:

• NXP SmartMX3 P71D321 Java Card
• P71D321 Contact Java Card
• P71D321 Contactless Java Card
• P71D321 Dual Interface Java Card
• NXP SmartMX3 P71D600 Java Card
• P71D600 High-Memory Java Card
• JCOP 4 / SmartMX3 Java Cards
• JCOP 4.5 P71D600 Java Cards
• Custom Java Card and applet configurations

Contact us to confirm the required NXP SmartMX3 Java Cards chip, JCOP version, memory configuration, interface, applet requirements, personalization and minimum order quantity.

Frequently Asked Questions

What is an NXP SmartMX3 Java Card?

An NXP SmartMX3 Java Cards is a smart card built using an NXP SmartMX3 secure microcontroller and a compatible Java Card operating system such as JCOP. SmartMX3 provides the secure hardware platform, while JCOP provides the Java Card and GlobalPlatform environment.

What is NXP SmartMX3 P71D321?

P71D321 is a SmartMX3 secure microcontroller platform from NXP designed for high-security applications. NXP identifies it as a contact and dual-interface controller and offers JCOP as a system solution.

What is NXP SmartMX3 P71D600?

P71D600 is a high-memory SmartMX3 security microcontroller platform. NXP lists memory up to 450 KB and positions the device for applications including eGovernment, access management and transportation.

Does P71D321 support Java Card?

Yes. NXP states that JCOP 4 can run on the P71D321 and provides a full Java Card operating-system solution for the platform.

What Java Card version does JCOP 4 support?

NXP’s JCOP 4 documentation identifies support for Java Card 3.0.5 Classic Edition and GlobalPlatform configurations.

Does SmartMX3 support contactless Java Cards?

Yes. JCOP 4 supports contactless communication and ISO 14443, and SmartMX3 P71D321 is positioned for contactless and dual-interface applications.

What is the difference between P71D321 and P71D600?

P71D321 is a SmartMX3 platform positioned for secure contact and dual-interface applications, with flash configurations up to 344 KB and up to 500 KB NVM depending on implementation. P71D600 is positioned as a newer high-memory SmartMX3 platform with up to 450 KB memory.

Which SmartMX3 Java Card is suitable for high-memory applications?

The P71D600 is the more appropriate SmartMX3 platform when high memory is a primary requirement. Current P71D600-based JCOP products such as the J3R452 are available with approximately 450 KB flash and dual-interface communication.

Can SmartMX3 Java Cards support multiple applications?

Yes. JCOP is designed for multi-application smart card environments, allowing different secure applications or applets to operate under GlobalPlatform management.

Can I order a custom SmartMX3 Java Card?

Customisation can depend on the JCOP version, chip configuration, applet requirements, personalization, interface configuration and card manufacturer. The exact available configuration should be confirmed before ordering.
