MIFARE Classic EV1

MIFARE Classic EV1 – Buy MIFARE Classic EV1 Java Smart Card

The MIFARE Classic EV1 – Buy MIFARE Classic EV1 Java Smart Card is a widely used contactless smart card based on NXP MIFARE technology and designed for applications requiring reliable contactless identification, access control, ticketing, and secure data storage. The MIFARE Classic® EV1 1K – 4K MF1ICS50 IC operates according to ISO/IEC 14443 Type A, providing compatibility with a broad range of contactless card readers and smart card systems.

The MIFARE Classic EV1 is particularly suitable for public transportation, access control, employee identification, event ticketing, parking systems, school and campus cards, and electronic access management. Its proven contactless technology enables fast card transactions, making it an excellent choice for high-volume environments where speed and convenience are important.

Features

MIFARE, RF Interface (ISO/IEC 14443 A)

• Contactless transmission of data and supply energy (no battery needed)
• Operating distance: Up to 100mm (depending on antenna geometry)
• Operating frequency: 13.56 MHz
• Data transfer: 106 kbit/s
• Data integrity: 16-Bit CRC, parity, bit coding, bit counting
• Anti-collision
• Typical ticketing transaction: < 100 ms (including backup management)

EEPROM

• 1 kB – 4 kB, organized in 16 sectors with 4 blocks of 16 bytes each (one block consists of 16 bytes)
• User-definable access conditions for each memory block
• Data retention of 10 years
• Write endurance 100.000 – 200.000 cycles

Security

• Mutual three-pass authentication (ISO/IEC DIS 9798-2)
• An individual set of two keys per sector (per application) to support multiapplication with key hierarchy
• A unique serial number for each device

Delivery options

• Die on wafer
• Bumped die on wafer
• MOA4 or MOA2 contactless card module

MIFARE Classic EV1 Contactless Smart Card

The integrated anti-collision mechanism allows multiple MIFARE cards to be present within the reader’s operating field simultaneously. The system can identify and select individual cards so that transactions are performed with the selected card without interference from other cards in the field.

The MIFARE Classic EV1 MF1ICS50 is designed for straightforward integration into contactless smart card systems. Fast transaction processing can help reduce waiting times at access gates, transportation terminals, and other high-throughput locations. Users can also conveniently present the card without necessarily removing it from a wallet, depending on the reader and card environment.

Buy MIFARE Classic EV1 Java Smart Card

If you are looking to buy MIFARE Classic EV1 Java Smart Card, the MIFARE Classic® EV1 1K – 4K MF1ICS50 provides a practical contactless card platform for transportation, identification, access management, and ticketing applications. Its ISO/IEC 14443 Type A interface and established MIFARE ecosystem make it suitable for integration with compatible RFID and contactless smart card readers.

MIFARE Classic® EV1 1K – 4K Applications

Consumer Applications

• Access control cards
• Car parking systems
• Employee identification cards
• Event ticketing
• Public transportation cards
• School and campus cards
• Membership and loyalty cards
• Contactless identification

Industrial Applications

• Access management
• Electronic toll collection
• Secure facility access
• Workforce identification
• Parking management
• Transportation and transit systems

MIFARE Classic® EV1 1K – 4K Key Benefits

• MIFARE Classic® EV1 1K – 4K MF1ICS50 technology
• Contactless smart card solution
• ISO/IEC 14443 Type A compatible
• Integrated anti-collision functionality
• Suitable for high-throughput applications
• Fast contactless transaction processing
• Suitable for RFID and smart card systems
• Widely used for transportation and access applications
• Compatible with MIFARE-based infrastructure
