Buy JCOP 4 EMV Java Card OS for SmartMX3 Secure Microcontrollers
JCOP 4 EMV P71 Java Card
- Product Name: JCOP 4 EMV P71
- Description: A field-proven, vendor-independent OS for chip-card applications. It provides multi-application support for dual-interface, contactless and contact formats, and delivers benchmark transaction performance for EMV payment whether on card or other form factors.
- Java Card version 3.0.5 Classic and GlobalPlatform 2.3
- Up to 220kB of flash memory (CMOS040 technology) and optional MIFARE and contactless options
- Cryptography including DES/TDES, AES 256, RSA 2048, ECC, and SHA-1/2
- EMVCo hardware and platform approvals as well as certifications from Visa, MasterCard, Discover, Amex, and JCB
- Support for EMV specifications and applications from Visa, MasterCard, Discover, Amex, EMVCo
- Order: Buy JCOP 4 EMV Java Card
JCOP 4 EMV P71
JCOP 4 EMV P71 – Buy JCOP 4 EMV Java Card OS for Payment and Transit
JCOP 4 EMV P71 Java Card, including: – Java Card version 3.0.5 Classic and GlobalPlatform 2.3 – Up to 220kB of flash memory (CMOS040 technology) and optional MIFARE and contactless options – Cryptography including DES/TDES, AES 256, RSA 2048, ECC, and SHA-1/2 – EMVCo hardware and platform approvals as well as certifications from Visa, MasterCard, Discover, Amex, and JCB – Support for EMV specifications and applications from Visa, MasterCard, Discover, Amex, EMVCo, etc.
Common Criteria EAL 6+ certified and EMVCo approved, JCOP is optimized for use with NXP’s SmartMX3 family, a line of secure microcontrollers with hardware accelerators.
JCOP supports every SmartMX3 crypto algorithm and delivers best-in-class transaction performance and personalization time.
Customers can create their own single or multiple Java Card applets with JCOP, or get a head start on design by using NXP’s available applets. Additionally, NXP can support customer-designed Applets loaded to Flash memory.
The NXP offering for JCOP includes cost-effective solutions based on advanced CMOS040 technologies.
Key Features
| Java Card v3.0.5 Classic |
| GlobalPlatform® |
| – GP v2.2 Mapping Guidelines configuration v1.0.1 |
| – GP v2.3 Financial Configuration v1.0 (config 2) |
| – GP v2.3 Common Implementation Configuration v2.0 |
| – Common Criteria EAL 5+ certified (supports 3DES, RSA, AES) |
| ISO 7816-3 T=0, T=1 (223.2 kbps) |
| ISO 14443 (up to 848 kbps) |
| Dual-interface support |
| Available Flash memory (up to 200 KB) |
| Highly flexible feature and Applet selection for Flash preloading for customer-specific products |
| MIFARE Plus®/MIFARE Classic® EV1 or MIFARE® DESFire® EV2 implementations |
| Additional features via OS Addon in JCOP 4 EMV P71 |
| Support (optional) |
| – Korean SEED support (optional) |
| – Match on Card (optional) |
| Additional features via OS Addon in JCOP 4 SecID |
| – Global Platform ID Configuration |
| – RSA Key Generation |
| – FIPS 140-2 |
Key Benefits
| Unique platform supports convergence of payment, transport and e-government, increasing flexibility while reducing cost and complexity |
| Easy implementation with full range of certified applets available for loading to FLASH, improving time-to market, offering highest customization |
| Optimized for high performance OS initialization and personalization for excellent machine utilization and throughout |
| JCOP best-in-class transaction speed – from border control gates to contactless payment terminals, and automatic fare-collection schemes – enabling a differentiated customer experience. |
| Trusted Java Card OS platform based on current and future NXP secure ICs with highest certified security level, ensuring reliable project deployment |
APPLICATIONS
Approved VISA®, MasterCard®, Discover/Diners Club®, and American Express® applications available UPI® (Union Pay International) and qSPARC 2.0 (India) applications available JCB available in Q4 2019 Additional features in JCOP 4 SecID:
- National eID
- Electronic passport
- Electronic health card
- Logical and physical access
- Digital signature card
- Micro payment
- Public transport
PRODUCT FEATURES – JCOP 4 EMV P71
| Specifications and Features | JCOP 4 EMV P71 |
|---|---|
| Java Card version | 3.0.5 Classic |
| GlobalPlatform | 2.3 |
| SCP | SCP01 / 02 / 03 |
| Delegated management | Yes |
| Secure box | Yes |
Available Memory and Technology
| Feature | Specification |
|---|---|
| FLASH (available before loading MIFARE, Applets, OS Addons) | Up to 200 kB |
| CMOS technology | CMOS040 |
MIFARE Options
| Feature | Specification |
|---|---|
| MIFARE DESFire EV2 | Optional |
| MIFARE Plus EV1 | Optional |
Payment
| Feature | Specification |
|---|---|
| Transaction time (M/Chip reference Transaction @ M/Chip Advance) | < 200 ms |
Cryptography
| Algorithm | Specification |
|---|---|
| DES / TDES | 56 / 112 / 168 bit |
| AES | 256 bit |
| RSA | 2048 bit (4096 bit) |
| ECC GF(p) | Available on SecID configuration |
| SHA | SHA-1 / SHA-2 |
Certifications and Approvals
| Certification | Status |
|---|---|
| EMVCo hardware approval | Yes |
| EMVCo platform approval | Yes |
| VISA approvals | Yes |
| MasterCard PIC (TAS & CAST) | Yes |
| Discover / Diners Club | Yes |
| American Express | Yes |
| JCB | Yes |
| EMVCo CPA | Yes |
| Common Criteria (VAN5) for OS | EAL 6+ |
Buy JCOP 4 EMV Java Card
Buy JCOP 4 EMV Java Card from Aft India.
