Rockey4 Smart

Rockey4 Smart Software Protection Dongle – Ultimate Hardware Key for Windows 2000/XP/2003/Vista/7, Linux, and Mac OS

ROCKEY4 SMART is a cutting-edge software protection dongle that utilizes smart card-based hardware for enhanced security and integration. Engineered with a robust architecture, its design ensures comprehensive protection mechanisms and high-level system integration. The embedded smart card chip and its manufacturer are certified under internationally recognized EAL 4+ and ITSEC standards, ensuring reliable and secure performance. The device also complies with ISO/IEC 10373, undergoing rigorous testing against ultraviolet radiation, X-rays, electromagnetic interference, and other environmental factors to guarantee long-term stability and durability.

Designed for advanced hardware-level security, the smart card chip in ROCKEY4 SMART is built to resist sophisticated attacks, including Simple Power Analysis (SPA), Differential Power Analysis (DPA), and physical tampering (e.g., SiShell attacks). From its initial design phase, the chip incorporates advanced protection techniques such as noise generation, signal interference, noise filtering circuits, and special protective materials, making it virtually impossible to audit or reverse-engineer runtime instructions. A hardware-based random number generator, managed by the CPU, secures communication data with strong encryption and randomization.

Evolved from the proven ROCKEY4 dongle line, ROCKEY4 SMART adopts a fully driverless architecture, supporting seamless integration with Windows (2000/XP/2003/Vista/7), Linux, and macOS. This plug-and-play functionality simplifies deployment and maintenance across multiple platforms. The dongle also offers expanded memory capacity and supports a broader range of user-defined algorithms, enabling more complex software protection schemes.

For existing ROCKEY4 users, upgrading to ROCKEY4 SMART is effortless—there’s no need for extensive reprogramming. A simple recompilation of your code is all that’s required to migrate your application and take full advantage of the enhanced features and security of ROCKEY4 SMART.

Features:

• User definable 8 bytes dongle password
• Universal unique hardware ID
• 2 levels-4 groups (basic password & advanced password) password management mechanism, i.e. developer password and end-user password •Built-in seed code algorithm
• Compliant with CE and FCC standards. Support multiple operating systems: Windows 2000 / XP / 2003 / Vista / 7, Linux and Mac OS
• License management function
• Communication datagram encrypted against interception
• Provide shell encryption tool
• 1,000 bytes user space
• Provide 64 module control units
• Support for 128 user defined algorithms
• Standard USB 1.1 device, support USB 2.0 interface
• Provide multiple software programming interfaces: Delphi, Power Builder, Python, Fortran, Java, RealBasic, Oracle, SQL2000, FoxPro, VB, VBA, VC, C# and VB.NET etc.

More Features:

1. Smart card based software protection Key
2. Hardware based soft clock
3. User definable 8 bytes dongle password
4. Universal unique hardware ID
5. 2 levels-4 groups (basic password & advanced password) password management mechanism, i.e. developer password and end-user password
6. Built-in seed code algorithm
7. Compliant with CE and FCC standards.
8. Support multiple operating systems: Windows 2000/XP/2003/Vista/7,Linux and Mac OS
9. License management function
10. Communication datagram encrypted against interception
11. USB driverless device
12. Provide shell encryption tool
13. 1,000 bytes user space
14. Provide 64 module control units
15. Support for 128 user defined algorithms
16. Standard USB 1.1 device, support USB 2.0 interface
17. Provide multiple software programming interfaces: Delphi, Power Builder, Python, Fortran, Java, RealBasic, Oracle, SQL2000, FoxPro, VB, VBA, VC, C# and VB.NET etc.

Specification

ROCKEY4 SMART – Secure, Driverless Software Piracy Protection Dongle with Advanced Smart Card Technology

Specification	Details
CPU	8-bit Smart Card Processor
Certification	CE, FCC, EAL 4+, IT SEC
Hardware Series Number	Global Unique Hardware ID
Memory Space	2000 bytes
Built-in Algorithm	Seed Code, Random Number, User-Defined Algorithms, DES, 3DES, RSA
Built-in Clock	Time License
Read Times	Unlimited
Write Times	≥ 100,000
Interface Type	USB Type A
Interface Standard	Standard USB 1.1, Compatible with USB 2.0
Platform Support	Windows XP/2000/2003/Vista/7, Linux, MacOS, WinCE
Appearance Color	Varies (Customizable)
Encryption Method	Shell Encryption, Programming API
Dimensions & Weight	50 x 17 x 7 mm, 6g (Model A1+)
Casing Material	Polycarbonate (PC)
Operating Temperature	0°C to 70°C
Storage Temperature	-10°C to 80°C
Humidity Tolerance	20% – 80%
Cascade Levels	Supports up to 16
Power Supply	USB Powered
Working Power Consumption	≤ 250 mW
Working Voltage	5V
Working Current	≤ 50mA
Data Retention Period	Minimum 10 Years
